FOR SALE: TOSHIBA BTD-110.R16 CNC HORIZONTAL BORING MILL (2000) – HEAVY-DUTY PRECISION TABLE TYPE BORING MACHINE

We are offering a 2000 Toshiba BTD-110.R16 Horizontal CNC Boring Mill, a robust and high-precision table-type boring machine engineered for large-part machining, heavy cutting applications, and demanding industrial environments.

Manufactured in Japan and equipped with the advanced TOSNUC 888 CNC Control, B-axis rotary table, 38-tool ATC, and integrated quill spindle assembly, this machine is ideal for energy, oil & gas, heavy equipment, mold & die, and large fabrication industries.

Condition: Needs Work
Location: Canada

MACHINE SPECIFICATIONS

Manufacturer: Toshiba
Model: BTD-110.R16
Year: 2000
Machine Type: Horizontal Table Type CNC Boring Mill
Control: TOSNUC 888 CNC Control
Country of Manufacture: Japan

TRAVELS & AXES

X-Axis Travel: 2,000 mm (2.000 m)
Y-Axis Travel: 1,500.1 mm (1.500 m)
Z-Axis Travel: 1,450.1 mm (1.450 m)
W-Axis (Quill Travel): 549.91 mm (0.550 m)
B-Axis: 360° Rotary Table

The 4-axis configuration with full B-axis rotary table allows multi-face machining in a single setup, significantly improving accuracy and productivity.

TABLE CAPACITY

Table Width: 1,501.6 mm (1.502 m)
Table Length: 1,599.9 mm (1.600 m)
Maximum Table Load: 13,889 lbs (6,300 kg approx.)

Heavy-duty table design supports large and heavy workpieces with excellent rigidity.

SPINDLE & PERFORMANCE

Spindle Diameter: 109.98 mm
Spindle Taper: 7/24 No. 50 (BT-50)
Spindle Speed: 3,000 RPM
Spindle Motor Power: 14.9 kW

The integrated quill spindle assembly delivers strong torque for heavy roughing while maintaining precision for finishing operations.

TOOL CHANGER

Automatic Tool Changer: 38 ATC
Tooling Type: BT-50
Included Tooling: Assorted BT-50 Tooling

Designed for reduced setup times and efficient multi-tool operations.

RAPID TRAVERSE RATES

Rapid Traverse (X/Y/Z): 393 in/min (approx. 10 m/min)
Rapid Traverse (W): 196 in/min (approx. 5 m/min)

Ensures efficient positioning and reduced non-cutting time.

ACCURACY

Positioning Accuracy: 0.0152 mm
Repeatability: 0.0076 mm

Delivers high-precision performance suitable for tight-tolerance applications.

ELECTRICAL & CONTROL

Control System: TOSNUC 888 CNC
Servo System: Toshiba/Shibaura Servo Amplifier Rack
Axis Servo Drives: Toshiba Axis Servo Drives
Spindle Monitoring: Spindle Load Meter

Toshiba’s proprietary control system is known for stability, durability, and long-term industrial reliability.

MACHINE DIMENSIONS & WEIGHT

Overall Dimensions:
236.22" x 200.79" x 153.54"
(6.000 m x 5.100 m x 3.900 m approx.)

Machine Weight: 121,000 lbs (54,885 kg approx.)

Heavy cast construction provides exceptional rigidity and vibration dampening.

MACHINE IS EQUIPPED WITH

✔ B-Axis 360° Rotary Table
✔ TOSNUC 888 CNC Control
✔ Portable Hand Pendant
✔ Integrated Quill Spindle Assembly
✔ 38-Tool Automatic Tool Changer
✔ Full-Length Chip Conveyor
✔ Coolant Tank & Pump System
✔ Full Machine Guarding Enclosure
✔ Adjustable Pendant Mounting Arm
✔ Toshiba/Shibaura Servo Amplifier Rack
✔ Toshiba Axis Servo Drives
✔ Spindle Load Meter
✔ Assorted BT-50 Tooling

MACHINE OVERVIEW

The Toshiba BTD-110.R16 is a heavy-duty horizontal boring mill designed for large-part machining and high-torque applications. It is an excellent solution for:

✔ Energy and power generation components
✔ Oil & gas equipment
✔ Heavy fabrication parts
✔ Large mold & die applications
✔ Industrial machinery bases and housings

With its rigid construction, powerful spindle, full rotary table, and high-capacity tool changer, this machine provides dependable performance for demanding machining operations.
